| ITEM |
Diameter(mm) |
Pitch P (mm) |
Inside Width |
Weight/m |
Proof Load (KN) |
Breaking Load (KN) |
| G8H-11 |
11 |
43 |
12.5 |
2.34 |
120 |
150 |
| G8H-14 |
14 |
50 |
17 |
3.95 |
200 |
250 |
| G8H-16 |
16 |
55 |
18.5 |
5.21 |
260 |
320 |
| G8H-18 |
18 |
64 |
21 |
6.93 |
330 |
410 |
| G8H-19 |
19 |
64 |
21 |
7.36 |
360 |
450 |
| G8H-22 |
22 |
86 |
26 |
9.4 |
490 |
610 |
|
 |
|
. |
|
