| ITEM |
Chain Size D (mm) |
Pitch P (mm) |
Inside Width B (mm) |
Weight (kg/m) |
S.W.L (KN) |
Proof Load (KN) |
| SHORT |
| PUC-6 S |
6 |
18 |
9 |
0.78 |
2.6 |
6.7 |
| PUC-8 S |
8 |
24 |
12 |
1.38 |
4.7 |
11.8 |
| PUC-9 S |
9 |
27 |
14 |
1.75 |
6.00 |
14.9 |
| PUC-11 S |
11 |
33 |
17 |
2.61 |
8.9 |
22.3 |
| PUC-13 S |
13 |
39 |
20 |
3.64 |
12.4 |
31.2 |
| PUC-16 S |
16 |
48 |
24 |
5.51 |
18.8 |
47.2 |
| PUC-19 S |
19 |
57 |
29 |
7.77 |
25.7 |
66.6 |
| PUC-22 S |
22 |
66 |
33 |
10.41 |
35.7 |
89.2 |
| LONG |
| PUC-6 L |
6 |
24 |
9 |
0.71 |
2.6 |
6.7 |
| PUC-8 L |
8 |
32 |
12 |
1.25 |
4.7 |
11.8 |
| PUC-9 L |
9 |
36 |
14 |
1.58 |
6.00 |
14.9 |
| PUC-11 L |
11 |
44 |
17 |
2.36 |
8.9 |
22.3 |
| PUC-13 L |
13 |
52 |
20 |
3.30 |
12.4 |
31.2 |
| PUC-16 L |
16 |
64 |
24 |
5.00 |
18.8 |
47.2 |
| PUC-19 L |
19 |
76 |
29 |
7.04 |
25.7 |
66.6 |
| PUC-22 L |
22 |
88 |
33 |
9.44 |
35.7 |
89.2 |
|
|
|
. |
|
