| ITEM |
Chain Size D(mm) |
Pitch P (mm) |
Outside Width B(mm) |
Weight (kg/m) |
S.W.L (ton) |
Breaking Load (KN) |
| HC-6 |
6.3 |
19 |
22 |
0.86 |
1.25 |
50 |
| HC-7 |
7.1 |
21 |
25 |
1.08 |
1.6 |
63 |
| HC-8 |
8 |
24 |
28 |
1.34 |
2 |
80 |
| HC-9 |
9 |
27 |
32 |
1.79 |
2.5 |
100 |
| HC-10 |
10 |
30 |
35 |
2.17 |
3.2 |
128 |
| HC-11 |
11.2 |
34 |
39 |
2.65 |
4 |
160 |
| HC-12 |
12.5 |
38 |
44 |
3.33 |
5 |
200 |
|
|
|
. |
|
